Johnson Controls YORK YK Style G OPTIVIEW - FIGURE 10 - System Components Rear View

SECTION 3 - SYSTEM COMPONENTS DESCRIPTION
JOHNSON CONTROLS
19
FORM 160.75-O1 (211)
3
LD15223
FIGURE 10 - SYSTEM COMPONENTS REAR VIEW
DISCHARGE
LINE
COMPRESSOR
OIL PUMP
HOUSING
LIQUID LINE
REAR VIEW
MOTOR
CONDENSER
