Johnson Controls YORK YK Style G OPTIVIEW - FIGURE 17 - Motor Starter Temperature and Insulation Resistances

SECTION 6 - MAINTENANCE
JOHNSON CONTROLS
31
FORM 160.75-O1 (211)
LD00476
FIGURE 17 - MOTOR STARTER TEMPERATURE AND INSULATION RESISTANCES
Minimum Insulation Resistance vs. Temperature (per IEEE Std 43)
Open Motors
TEMPERATURE – °F
MEGOHMS
6
