SECTION 2 - OPTIVIEW CONTROL CENTER INTRODUCTION
SLOT
NUMBER
DESCRIPTION
2847 ACC: Surge Margin
2848 ACC: Manual Surge Command
2849 ACC: Surge Map Count
2850 ACC: Surge Type
2857 ACC: Surge Map Point Count
2858 ACC: Surge Map Delta P/P
2859 ACC: Surge Map Output Frequency
2860 ACC: Surge Map PRV Position
2861 Filter: Is Filter Installed
2862 Filter: Is Operation Inhibited
2863 Filter: Is Filter Running
2864 Filter: Is Precharge Contactor Closed
2865 Filter: Is Supply Contactor Closed
2866 Filter: Phase Rotation
2867 Filter: Motor HP
2868 Filter: Supply kVA
2869 Filter: Total Power Factor
2870 Filter: DC Bus Voltage
2871 Filter: Heatsink Temperature
2872 Filter: L1 - L2 RMS Voltage
2873 Filter: L2 - L3 RMS Voltage
2874 Filter: L3 - L1 RMS Voltage
2875 Filter: L1 - N Peak Voltage
2876 Filter: L2 - N Peak Voltage
2877 Filter: L3 - N Peak Voltage
2878 Filter: L1 Total Harmonic Distortion
2879 Filter: L2 Total Harmonic Distortion
2880 Filter: L3 Total Harmonic Distortion
2881 Filter: L1 RMS Filter Current
2882 Filter: L2 RMS Filter Current
2883 Filter: L3 RMS Filter Current
2884 Filter: L1 RMS Supply Current
2885 Filter: L2 RMS Supply Current
2886 Filter: L3 RMS Supply Current
2887 Filter: L1 Total Demand Distortion
2888 Filter: L2 Total Demand Distortion
2889 Filter: L3 Total Demand Distortion
2890 Filter: Maximum Total Harmonic Distortion
2891 Filter: Maximum Total Demand Distortion
8192 Oil: Pump Pressure
8193 Oil: Sump Pressure
8194 Oil Seal Lube: Is Control Enabled
8195 Oil Seal Lube: Time To Next Lube
SLOT
NUMBER
DESCRIPTION
8196 Oil Seal Lube: Time Left
8197 VSOP: Speed Command
8198 VSOP: Control Mode
8199 VSOP: Manual Command Frequency
8200 VSOP: Is Pulldown In Effect
8201 VSOP: Pulldown Time Remaining
8202 VSOP: Target Setpoint
8203 VSOP: Pressure Setpoint
8204 VSOP: Control Period
8205 Refrigerant Level: Is Control Enabled
8206 Refrigerant Level: Position
8207 Refrigerant Level: Is Valve Closing
8208 Refrigerant Level: Is Valve Opening
8209 Refrigerant Level: Control Mode
8210 Refrigerant Level: Is Pulldown In Effect
8211 Refrigerant Level: Pulldown Time Remaining
8212 Refrigerant Level: Target Setpoint
8213 Refrigerant Level: Setpoint
8214 Refrigerant Level: Period
8215 Refrigerant Level: Proportional Limit Close
8216 Refrigerant Level: Proportional Limit Open
8217 Refrigerant Level: Rate Limit Close
8218 Refrigerant Level: Rate Limit Open
8221 HSTB: Oil Drain Temperature (Before
C.MLM.01.03)
8222 HSTB: Is Solenoid Installed
8223 HSTB: Is Solenoid On
8224 HSTB: Proximity Position
8225 HSTB: Proximity Differential
8226 HSTB: Proximity Reference Position
8280 Stall Detector Board output voltage
8281 VGD open
8282 VGD close
8317 Stall DC Pressure Voltage
TABLE 4 - MASTER SLOT NUMBERS LIST FOR
USE WITH TREND FEATURE (CONT'D)
TABLE 4 - MASTER SLOT NUMBERS LIST FOR
USE WITH TREND FEATURE (CONT'D)
