SECTION 4 - PRINTING
JOHNSON CONTROLS
211
FORM 160.54-O1
ISSUE DATE: 9/10/2014
4
[Skip the following section if Motor Type is not EM]
Electro-Mechanical Starter
----------------------------------------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
[Skip the following section if Motor Type is not Mod A
SSS]
Liquid-Cooled Solid State Starter
----------------------------------------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
Scale/Model = 600 V, 281 A
Supply Voltage Range = Disabled
Full Load Amps = 150 A
Current Imbalance Check = Disabled
[Skip the following section if Motor Type is not Mod B
SSS]
Liquid-Cooled Solid State Starter
----------------------------------------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
Starter Model = 26L
Voltage Range = 440 - 480
Full Load Amps = 275 A
Starting Current = 1150 A
Open SCR = Enabled
FIGURE 65 - SAMPLE PRINTOUT (SETPOINTS) (CONT'D)
Shorted SCR = Disabled
[Skip the following section if Motor Type is not VSD]
Variable Speed Drive
----------------------------------------------------------------------------------
Local Motor Current Limit = 100 %
Remote ISN Current Limit = 100 %
Remote Analog Current Limit = 100 %
Remote Digital Current Limit = 100 %
Remote Modem Current Limit = 100 %
Pulldown Demand Limit = 100 %
Pulldown Demand Time = 0 Min
Motor HP = 351 HP
Power Line Frequency = 60Hz
[Skip the following section if Motor Type is not VSD]
Harmonic Filter Data
----------------------------------------------------------------------------------
Filter Operation = Enabled
Motor HP = 351 HP
[Skip the following section if Motor Type is not VSD]
Adaptive Capacity Control
----------------------------------------------------------------------------------
Surge Margin Adjust = 0 Hz
Stability Limit = 4500
FIGURE 65 - SAMPLE PRINTOUT (SETPOINTS) (CONT'D)
