Johnson Controls YORK YK Style G OPTIVIEW User Manual

JOHNSON CONTROLS
3
FORM 160.75-N1
ISSUE DATE: 4/30/2014
CHANGEABILITY OF THIS DOCUMENT
In complying with Johnson Controls’ policy for contin-
uous product improvement, the information contained
in this document is subject to change without notice.
Johnson Controls makes no commitment to update or
provide current information automatically to the man-
ual owner. Updated manuals, if applicable, can be ob-
tained by contacting the nearest Johnson Controls Ser-
vice office or accessing the Johnson Controls QuickLIT
website at http://cgproducts.johnsoncontrols.com.
Operating/service personnel maintain responsibility for
the applicability of these documents to the equipment.
If there is any question regarding the applicability of
these documents, the technician should verify whether
the equipment has been modified and if current litera-
ture is available from the owner of the equipment prior
to performing any work on the chiller.
CHANGE BARS
Revisions made to this document are indicated with a
line along the left or right hand column in the area the
revision was made. These revisions are to technical in-
formation and any other changes in spelling, grammar
or formatting are not included.
ASSOCIATED LITERATURE
MANUAL DESCRIPTION FORM NUMBER
Solid State Starter (Mod “B”) – Operation and Maintenance 160.00-O2
Variable Speed Drive – Operation 160.00-O1
Installation – Unit 160.54-N1
Operation – OptiView Control Panel 160.54-O1
Renewal Parts – Unit 160.75-RP1
Renewal Parts – OptiView Control Center 160.54-RP1
Wiring Diagram – YK Chiller (Style G) Field Control Modications 160.75-PW4
Wiring Diagram – YK Chiller (Style G) OptiView Control Center with Remote Low or Medium Voltage EMS 160.75-PW5
Wiring Diagram – YK Chiller (Style G) OptiView Control Center with Unit Mounted Low or Medium
Voltage SSS, Unit Mounted Low Voltage VSD with Modbus, or Remote Medium Voltage VSD
160.75-PW6
Wiring Diagram – YK Chiller (Style G) OptiView Control Center with LTC I/O Board with Remote Low
or Medium Voltage EMS
160.75-PW7
Wiring Diagram – YK Chiller (Style G) OptiView Control Center with LTC I/O Board with Unit Mounted
Low or Medium Voltage SSS, Unit Mounted Low Voltage VSD with Modbus or Remote Medium
Voltage VSD
160.75-PW8
Maintenance Requirements Log Sheets 160.54-MR1
Installation and ReAssembly - Unit 160.75-N3
Operation - Unit 160.75-O1

Johnson Controls YORK YK Style G OPTIVIEW Specifications

General

Brand	Johnson Controls
Model	YORK YK Style G OPTIVIEW
Category	Chiller
Language	English
