FORM 160.75-O1 (211)
CHANGEABILITY OF THIS DOCUMENT
In complying with Johnson Controls’ policy for contin-
uous product improvement, the information contained
in this document is subject to change without notice.
While Johnson Controls makes no commitment to up-
date or provide current information automatically to
the manual owner, that information, if applicable, can
be obtained by contacting the nearest Johnson Controls
Service office.
Operating/service personnel maintains the responsi-
bility of the applicability of these documents to the
competitive equipment the kit is installed on. If there
is any question regarding the applicability of these
documents, the technician should verify whether the
equipment has been modified and if current literature
is available with the owner of the equipment prior to
performing any work on the chiller.
ASSOCIATED LITERATURE
MANUAL DESCRIPTION FORM NUMBER
Variable Speed Drive – Operation 160.00-O1
Solid State Starter – Operation and Maintenance 160.00-O2
Floor Mounted MV SSS – Operation 160.00-O5
Unit Mounted MV SSS – Operation 160.00-O7
Installation – Unit 160.75-N1
Optiview™ Control Center – Operation and Maintenance 160.54-O1
Wiring Diagram – Field Connections for YK Chiller (Style G) OptiView Control Center with Remote Low
or Medium Voltage EMS or Unit Mounted Low or Medium Voltage SSS
160.75-PW1
Wiring Diagram – Field Connections for YK Chiller (Style G) OptiView Control Center with Remote
Medium Voltage SSS
160.75-PW2
Wiring Diagram – Field Connections for YK Chiller (Style G) OptiView Control Center with Remote
Medium Voltage VSD
160.75-PW3
Wiring Diagram – Field Control Modications for YK Chiller (Style G) 160.75-PW4
Wiring Diagram – YK Chiller (Style G) OptiView Control Center with Remote Low or Medium Voltage EMS 160.75-PW5
Wiring Diagram – YK Chiller (Style G) OptiView Control Center with Unit Mounted Low or Medium
Voltage SSS, Unit Mounted Low Voltage VSD with Modbus, or Remote Medium Voltage VSD
160.75-PW6
Wiring Diagram – YK Chiller (Style G) OptiView Control Center with LTC I/O Board with Remote Low or
Medium Voltage EMS
160.75-PW7
Wiring Diagram – YK Chiller (Style G) OptiView Control Center w/ LTC I/O Board with Unit Mounted Low
or Medium Voltage SSS, Unit Mounted Low Voltage VSD with Modbus or Remote Medium Voltage VSD
160.75-PW8
Renewal Parts – Unit 160.75-RP1
Renewal Parts – OptiView Control Center 160.54-RP1
