Page Issue 01
Chapter - Electrical System
9:5
VT551 - Maintenance
Ref WD 227 issue 01
Fuses
Ident. Description / Function
Rating (A)
12V/24V
Circuit(s) Ref. Location Notes
MCB Master Circuit Breaker 30/30 SE304 Relay Box
F01 Work Mode 10/10 SE304 Relay Box
F02 Auxiliary Engine Crank Solenoid 15/15 SE304 Relay Box
F03 Spare
F04 Spare
F05 Spare
F06 Additional Beacon 15/10 SE304 Relay Box Option
F07 Spare
F08 Node 2 20/20 SE304 Relay Box
F09 Spare
F10 Node 5 5/5 SE304 Relay Box
F11 Autolube, Cowl Work Lamp 10/10 SE304 Relay Box Option
F12 Node 1 20/20 SE304 Relay Box
F13 Worklamps 15/10 SE304 Relay Box
F14 Node 3 & Node 4 15/15 SE304 Relay Box
F15 Beacon 15/15 SE304 Relay Box
