Johnston VT551 - Connectors Alphanumeric

Page Issue 01
Chapter - Electrical System
9:7
VT551 - Maintenance
WD 227 Issue 01
Connectors Alphanumeric
Ident. No.Ways Location
Harness Ref.
(Female)
Harness Ref.
(Male)
AL 2 Subframe – Autolube 293717-1
ALT-D 1 Auxiliary Engine – Alternator 293719-1
AR-1 4 Armrest Connector 293716-1 741928-1
AWB 2 Subframe – Additional Beacon 293717-1
AWL 2 Subframe – Additional Worklamp 293717-1
BEAC 5 Cab Beacon 293716-1
BEAC 2 Rear Beacon 293718-2
BEAC 2 Rear Beacon 293718-2
CAM 5 Camera Input 293716-1
CF 2 Chassis Fuel Tank 293717-1
CT 3 Subframe – CAN Terminator 293717-1
CVA 12 Switch Panel – CANView A 293716-1
CVB 12 Switch Panel – CANView B 293716-1
CVC 12 Switch Panel – CANView C 293716-1
CVD 17 Switch Panel 293716-1 293713-1
DAW 2 Front Valance – Discharge Buzzer 293726-1
DS1 2 Cowl Door – Limit Switch 293718-3
DS2 2 Cowl Door – Limit Switch 293718-3
ESC 2 Auxiliary Engine – Throttle Actuator 293719-1
ESOS 1 Auxiliary Engine – ESOS Valve 293719-1
ESS 3 Auxiliary Engine – Speed Sensor 293719-1
EWL 2 Engine Bay Worklamp 293717-1
F1 2 Fuel Tank #1 – Level Sensor 293717-1
F2 2 Fuel Tank #2 – Level Sensor 293717-1
FSS 3 Fancase – Fan Speed Sensor 293726-1
HOL 2 Hydraulic Tank – Oil Level 293725-1
HRW 2 Body – Hopper Raise Switch 293718-3
LA 2 FRL Unit – Air Pressure Switch 293717-1
LH-AWL 2 Body – Additional Worklight 293774-1
LMML 2 RH Cowl Door – Marker Light 293718-3
LRML 2 Rear of Body – LH Marker Light 293718-2
continues
