Chapter 3 INSTALLATION OF THE DISPLAY UNIT
3.9 CONNECTING TO AIS
3-28
Setting of JMA-3300
Baud Rate Setting
For details of operations, refer to "4.1 OPENING THE ADJUST MENU".
1 Hold down the [MENU] key.
"Code Input" screen appears.
2 Input "0" using the cursor keys, then press the [ENT] key.
"Adjust Menu" screen appears.
3 Press the cursor keys to select COM Port Setting , then press the [ENT]
key.
"COM Port Setting" screen appears.
4 Press the cursor keys to select Baud Rate , then press the [ENT] key.
"Baud Rate" screen appears.
5 Set 3.NMEA1 to 38400 bps.
Displaying AIS
1 Press the [MENU] key.
"Menu" screen appears.
2 Press the cursor keys to select Target , then press the [ENT] key.
"Target" screen appears.
3 Press the cursor keys to select AIS , then press the [ENT] key.
"AIS" screen appears.
4 Set to 2.ON.
The AIS function is activated.
To Next Page
