Chapter 3 INSTALLATION OF THE DISPLAY UNIT
3.12 CHANGE THE FUSE
3-34
3.12 CHANGE THE FUSE
Change the fuse as follows according to the scanner unit.
(At product delivery, the 10A normal fuse is provided.)
CAUTION
Use correct fuse ratings.
The use of incorrect ratings may cause an equipment failure.
Display Unit
Replace two fuses F2 and F3.
Table 3.12-1 List of fuses
F2 F3
Scanner unit model Details
Rating JRC code Rating JRC code
NKE-2042(DC12V) X-BAND/4kW 6.3A time-lag 5ZFCA00051
－ －
NKE-2042(DC24V) X-BAND/4kW 3.15A time-lag 5ZFCA00047
－ －
NKE-2043(DC12V) X-BAND/4kW 6.3A time-lag 5ZFCA00051
－ －
NKE-2043(DC24V) X-BAND/4kW 3.15A time-lag 5ZFCA00047
－ －
NKE-2062(DC12V) X-BAND/6kW 6.3A time-lag 5ZFCA00051 5A time-lag 5ZFCA00050
NKE-2062/HS(DC24V) X-BAND/6kW 3.15A time-lag 5ZFCA00047 5A time-lag 5ZFCA00050
NKE-2063(DC12V) X-BAND/6kW 6.3A time-lag 5ZFCA00051 5A time-lag 5ZFCA00050
NKE-2063/HS(DC24V) X-BAND/6kW 3.15A time-lag 5ZFCA00047 5A time-lag 5ZFCA00050
NKE-2103-4/4HS/6/6HS X-BAND/10kW 5A time-lag 5ZFCA00050 10A time-lag 5ZFCA00053
To Next Page
