Chapter 3 INSTALLATION OF THE DISPLAY UNIT
3.12 CHANGE THE FUSE
3-35
3
NSTALLATION MANUAL
Change the fuse
Remove the cover at the rear of the display unit as shown in the figure.
Remove
the screws.
The cover is
removed.
F3
F1
F1
