JRC JMA-3404 User Manual

APPENDIX
A-1
6
Adjust Menu
Item Setting Contents
1. Basic Adjustment
1. Bearing Adjustment 0.0 - 359.9㼻
2. Range Adjustment 0 - 999
3. Tune Adjustment 0 - 127
4. Antenna Height ~5m / 5~10m / 10~20m / 20m~ / USER
5. Language
English / Japanese / Language3 / Language4 / Language5 / ---- /
Language19 / Language20 / Custom
2. RADAR Echo
1. Noise Level 0 䇵 255
2. Main Bang Suppression
1. Main Bang Suppression Area 0 - 255
2. Main Bang Suppression Slope 0 - 255
3. Main Bang Suppression Level 0 - 255
3. Target Enhance Level Level1 / Level2 / Level3 / Level4
4. Gain
1. Preset 0 䇵 255
5. Sea
1. STC Curve Select Sea / River
2. STC Slope Correction 0.0 - 2.0
3. STC Offset 0 䇵 9, A - F
6. Rain
1. FTC Curve Select Sea / River
2. FTC Slope Correction 0.0 - 2.0
3. FTC Offset 0 䇵 9, A - F
3. Trails
1. Trails Suppression Distance 0 - 1000
2. Max Interval Short / Middle / Long / Super Long
3. Range Limit No Limit / Under 2 Range / Under 3 Range / Under 4 Range
4. TT
1. Vector Constant 1 䇵 8
2. Gate Display Off / On
3. Gate Size 0 - 64
5. Scanner
1. Slope Correction
2. PRF Fine Tuning 0 - 31
3. Stagger Trigger Off / On
4. Scanner Rotation Speed
1. SP1 0 - 7
2. SP2 0 - 7
3. SP3 0 - 7
4. MP1 0 - 7
5. MP2 0 - 7
6. LP1 0 - 7
7. LP2 0 - 7
5. PRF Output Mode Normal / Economy / High Power
6. Safety Switch TX-Off / Standby / TX-On / Ignore Error
7. Tune Peak Adjustment 0 䇵 127
8. Tune Indicator Level Adjustment 0 䇵 127
9. Stop antenna in the specified direction
1. ON/OFF Off / On
2. Angle 0 䇵 360
10. Ice Class Standby Mode Off / On
6. I/F Device
1. Heading Equipment AUTO / GYRO/Compass / GPS / Manual
