JRC JMA-3404 User Manual

A-21
APPENDIX
Item Setting Contents
1. Full Length 0.0 - 600.0
2. Full Width 0.0 - 200.0
3. GPS Antenna(Length) 0.0 - 600.0
4. GPS Antenna(Side) -100.0 - +100.0
5. Scanner(Length) 0.0 - 600.0
6. Scanner(Side) -100.0 - +100.0
3. Barge Outline
1. On/Off Off / On
2. Input Outline Size
1. Full Length 0.0 - 600.0
2. Full Width 0.0 - 200.0
3. Barge Position(Length) -600.0 - +600.0
4. Barge Position(Side) -200.0 - +200.0
4. Bearing Marker
1. Bearing Off / On
2. Bearing Step 0 – 99
5. Operation Numeric Display Off / On
6 Unit
1. Range NM / km / sm
2. Distance NM / km / sm
3. Speed kn / km/h / mph
4. Depth ft / fm/ m / user
5. User Depth 0.0001 - 9.9999
6. Temperature 䉝 / 䢛 F
7. Wind m/s / km/h / kt / Bft.
8. Size/Location Setting m / ft
7. Move Own Ship
1. Ship’s Move Lat/Lon / COG/SOG
8. Range
1. NM
1. 0.0625NM Off / On
2. 0.125NM Off / On
3. 0.25NM Off / On
4. 0.5NM Off / On
5. 0.75NM Off / On
6. 1NM Off / On
7. 1.5NM Off / On
8. 2NM Off / On
9. 3NM Off / On
10. 4NM Off / On
11. 6NM Off / On
12. 8NM Off / On
13. 12NM Off / On
14. 16NM Off / On
15. 24NM Off / On
16. 32NM Off / On
17. 48NM Off / On
18. 64NM Off / On
19. 72NM Off / On
2. km
1. 0.15km Off / On
2. 0.3km Off / On
3. 0.5km Off / On
4. 0.8km Off / On
5. 1.2km Off / On
