Chapter 1 INSTALLATION

To uniformly press the packing, gradually tighten diagonally in the following order.

The proper fastening torque of the fitting bolts (M8) is 1176 to 1470 N•cm (120 to 150kgf•cm).

Fig. 1-4-2-5

 Fastening of earth cable and application of seal

Fig. 1-4-2-6

Bolt the earth to mountbase and scanner.

Apply silicone sealant around the bolts.

4-M8 (stainless steel) bolt

Tightening torque: 120 to 150 kgf/cm

Precautions before Operation3
