JMA-9172-SA Instruction Manual > 3.BASIC OPERATION > 3.1 OPERATION FLOW
3－5
3
3.1.5 End the Operation and Stop the System
Exit
1) Press [TX/STBY] key.
The radar will stop transmission and the antenna will stop rotating.
at the upper left of the radar display changes to .
2) Press [POWER] key.
The system will be turned off.
Maintain the standby state if radar observation is restarted in a
relatively short time.Only pressing the [TX/STBY] key starts
observation.
!
• When conducting maintenance work, make sure to turn
off the power and make the main breaker OFF so that the
power supply to the equipment is completely cut off.
• Some equipment components can carry electrical
current even after the power switch is turned off, and
conducting maintenance work without unplugging the
power connector may result in electrocution, equipment
failure, or accidents.
Transmit
Standby
i

JRC JMA-9172-SA Specifications

General

Range	96 NM
Range Resolution	20 m
Azimuth Resolution	1.2°
Power Supply	24 VDC
Operating Temperature	-15°C to +55°C
Range Scales	0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 96 NM
Display	LCD
Frequency	9410 MHz ± 30 MHz
