JMA-9172-SA Instruction Manual > 3.BASIC OPERATION > 3.7 USE ROUTE FUNCTION
3－73
3
4) On the radar display, put the cursor on the line extending
between Waypoints that is to have its Planned Speed corrected.
The section that is to have its Planned Speed corrected is specified, and the new Planned
Speed is applied to the section.
5) To correct the Planned Speed of another section, repeat
procedures 3 and 4.
6) To finish correcting Planned Speed, left-click the
button.
The Planned Speed correcting mode will be cancelled.
(Example)
3.7.2.5 Deleting a Waypoint (Delete Waypoint)
The specified Waypoint in the route data saved in the radar system is deleted.
Procedures
1) Open the Set Route Sequence menu by performing the menu
operation below.
→
→
2) Left-click the button.
The Waypoint deleting mode is selected.
4. Correct Planned Speed
000
001
002
003
004
005
064T
8.00kn 9.00kn 10.0kn 11.0kn 12.0kn
113T 113T 064T
113T
Planned speed: 10.00kn
Section that is to have its Planned Speed corrected
Route
2. WPT/Route Setting
3. Set Route Sequence
5. Delete
