3－102
JMA-9172-SA Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
Setting color of each element
• Specify the color for the element.
• The color for the following elements can be specified.
3.8.5.3 Setting display brilliance (Brilliance Setting)
For each Day/Night mode, background color outside the bearing scale,
background color inside the bearing scale, and color for characters, radar echo and
radar trails can be selected.
Procedures
1) Open the Brilliance Setting menu by performing the menu
operation below.
→
→
: Night mode : Used under dark lighting conditions.
: The color of the background outside radar video PPI is
selected.
: The color of the background inside radar video PPI is
selected.
: The color of the character and bearing scale is selected.
: The color of the radar video is selected.
: The color of the time radar trails is selected.
: The color of the time radar trails is selected.
: The color of the target symbol is selected.
: The color of the cursor is selected.
: The color of the range rings is selected.
: The color of the EBL / VRM / PI is selected.
: The color of the own ship symbol, heading line, own
ship vector is selected.
i
Those selected color can be saved for each Day/Night mode.
Night
Outer PPI
Inner PPI
Character
RADAR Video
RADAR Trails(Time)
RADAR Trails(All)
Target Symbol
Cursor
Range Rings
EBL/VRM/PI
Own Symbol /HL/Vector
Main
7. Sub Menu
2. Brilliance Setting
