1) Check that the ship’s mains are turned on.
2) Press [POWER] key.
The system is turned on, and the preheating time is displayed.
is indicated at the upper left of the radar display.
3) Wait until the preheating time is over.
When the preheating time is over, the preheating time screen disappears, and
at the upper left of the radar display changes to .
4) Press [TX/STBY] key.
The radar will start transmission and the antenna will start rotating.
at the upper left of the radar display changes to .
NOTE:
The radar does not start transmission if you press [TX/STBY]
key while is indicated.
It will be displayed Tuning OK at the upper left of the radar display.
The radar system is optimum.If not displayed, Radar should be checked
by a service engineer.
