3-7
CAUTION
3.2.3 Tune
This radar system provides the automatic tune mode and the manual tune mode. The automatic tune
mode automatically adjusts the tuning of the transmitting frequency and the receiving frequency, and the
manual tune mode enables tuning to be adjusted by using the dial located on the operation panel.
Normally use the automatic tune mode. Only when the best tuning is not possible by the automatic tune
mode due to the deterioration of magnetron, use the manual tune mode.
The currently used tune mode is displayed in the area at the lower left of the display.
When using the automatic tune mode
Procedures 1 Press the [TUNE] dial to set the automatic tune mode.
Tune adjustment is automatically conducted in the automatic tune mode. Tune is adjusted
at the start of transmission, at the change of the range or pulse width. Tune adjustment is
completed within several seconds.
When using the manual tune mode
Procedures 1 Press the [TUNE] dial to set the manual tune mode.
2 Turn the [TUNE] dial to make adjustments so that the tuning bar is
maximized. The tuning bar is displayed in the area at the upper left of
the display.
Normally, use the automatic tune mode.
Use the manual tune mode only when best tuning is not
possible in the automatic tune mode due to
deterioration of magnetron.
To Next Page
