2-1
2.1
NAMES OF DISPLAY
Example of screen display
In this exam
ple, the screen i
s divided i
nto
a num
ber of areas and the nam
es in each area are
indicated.
PPI
Upper left
of the di
splay
Upper right
of the display
Lower left
of the di
splay
Lower right
of the display
Own ship's
informa
tion
Target
tracking (TT)/
AIS information
Digital information
Menu
Brilliance/
Display informatio
n
Alarm
73
75
