(7) Trial Maneuver : Manual Setting

Trial Course : 000.0° to 359.9°

Trial Speed : 0 to 100 knots

(8) Accuracy of Display : Complied with IMO Requirement

(9) System Failure Alarm : Visible / Audible Alarm

(10) Speed Input : Auto (LOG)

11.14 PERFORMANCE MONITOR (NJU-84)

(1) Dimensions : Width 130 x Depth 180 x Height 70 (mm)

(2) Mass : Approx. 0.7kg

(3) Operating Frequency : 3050±30MHz

11.15 PERFORMANCE MONITOR (NJU-85)

(1) Dimensions : Width 130 x Depth 149 x Height 70 (mm)

(2) Mass : Approx. 0.7kg

(3) Operating Frequency : 9410±30MHz
