3.3 Operation Procedures
y
y y
3.3.5 Basic Menu Operation
To open the menu:
By left-clicking the Main button located at the lower right of the radar display, the main menu
will open.
By left-clicking the buttons, TT , AIS , and AZ , adjacent to Main , each function's exclusive
menu will open.
For the arrangement of software buttons, see Section “2.3 FUNCTIONS OF SOFTWARE
BUTTONS”.
To close the menu:
By left-clicking the Target button, the menu will close and the target data display screen will
appear.
Alternatively, left-click Exit located at the bottom of the menu until the menu will close.
To move to a lower level of the menu:
The menu is in hierarchical structure. By left-clicking the software button for a desired menu item, it
is possible to move to the lower level of the menu. Alternatively, Press numeric keys corresponding to
the desired menu item number, and the mark will appear at the right end of a menu item having a
lower level.
To move to a higher level of the menu:
By left-clicking Exit at the bottom of the menu while the menu is open, it is possible to return to
the upper level of the menu.
