5-25
CAUTION
This function is provided to test if the target
tracking function is operating normally. Thus, do
not use the function except when you test the
target tracking function.
In particular, if the operation test mode is used
during navigation, pseudo targets appear on the
radar display and they are confused with actual
targets.
Do not use the mode during navigation.
Otherwise, an accident may result.
5.2.7 Operation Test (TT Test Menu)
The following functions are available for testing the target tracking function:
[I] Test Video Makes an operation check on the target detection circuit.
[II] TT Simulator Generates pseudo targets on the radar display in order to test if the target
tracking function is operating normally.
[III] Status Displays the status of the target tracking function.
[IV] Gate Display Displays the gate size for acquiring / tracking a target.
