JRC JMA-922B-9XA User Manual

5-60
5.7 Trial Maneuvering
yy
yyy
5
Trial Maneuvering in the True Vector Mode
In the True Vector mode, calculations are performed according to the values set by Trial Speed, Trial Course
and other features, and the result is displayed as a bold-line that represents the change of own ship’s vector as
shown in Fig. 5-7 (an example of the course changed to the right).
Example Fig. 5-7, the dangerous target forward left becomes safe as a result of simulation.
The tracked target information indicates the current CPA and TCPA values regardless of the result of
simulation.
Dangerous target
HL
Change of symbol
as a result of
trial maneuver
HL
TRIAL
NORMAL
Route
Own ship’s vector
Fig. 5-7 Trial Maneuvering in the True Vector Mode
