Wireless Goniometer (9RF308)
Used to convey funconal abilies concerning hand and extremity Range of
Moon (ROM).
1. If necessary, aach the Goniometer extension arms by aligning the
extension’s metal pins or holes with the metal pins or holes on the
Goniometer. Press straight down unl the extension makes contact with the
Goniometer arm.
2. If necessary, to remove the extension arms grasp the extension arm near
the metal pins and gently wiggle the extension as you pull it away from the
goniometer arm. Do not bend, or twist the extension to disengage as the
extension may break.
3. Push the “On” buon to enable communicaon with the Commander Echo
Console.
For instrucons on operang the Commander Echo Console, please refer
to the Console Secon of the manual.
For instrucons on performing specic tests, please refer to the oponal
Mulmedia Help System CD.
For troubleshoong informaon, please see page 43
For technical specicaons, please see page 56
Detachable Parts
Goniometer Extension arms (9AK113) - Aids in visual
conrmaon of alignment, or in aligning the Goniometer
to extremies. Comes in a set of two (2) arms.
Wrist Lanyard (7AC006) – The Wrist Lanyard is used to
help prevent dropping devices when carrying, or when
performing some tests.
