JTECH Medical COMMANDER ECHO - Graphic Symbol Definitions

3
© 2017 JTECH Medical MN022_M
Graphic Symbol Denions
Symbol Meaning
An ISO 7010-M002 symbol Consult Instrucons
An ISO 15223 symbol Keep Dry, do not immerse in water or other liquids

Informaon symbol
I P X N
An IEC 60529 symbol
IPXN, N=0 no protecon against ingress of water.
N=1 protecon against vercally falling water drops
An ISO 7000-0434A symbol Cauon
An IEC 60417-5840 symbol
Indicates type of protecon against electric shock:
Type B applied part
An IEC 60417-5140 symbol Non-Ionizing Radiaon
An ISO 15223 symbol Warning: devices are non sterile
FCC Logo
Commander Echo Console and Echo devices comply with Part 15 of
the FCC Rules
An IEC 60878 symbol
Indicang Degree of protecon against electric shock:
Class 2 Electrical equipment
An ISO 15223 symbol Indicang upper and lower temperature limits
An ISO 15223 symbol Indicang upper and lower humidity limits
An ISO 15223 symbol Indicang upper and lower atmospheric pressure limits
“Conformité Européenne”
(“European Conformity”)
Commander Echo Console and Echo devices meet the provisions of
the Council Direcve 93/42/EEC
An EN 980 symbol Idenfying the Manufacturer
An EN 980 symbol Idenfying the Authorized Representave for European Communies
An IEC 60878 symbol Signifying Alternang Current
An IEC 60878 symbol Signifying Direct Current
