– 38 –
#6
Function added to the needle up / down compensating switch (Function setting No. 93)
One stitch operation can be performed only when the needle up / down compensating switch is pressed at the time
of upper stop immediately after turning ON the power switch or upper stop immediately after thread trimming.
0 : Normal (Only needle up / down compensating stitching operation)
1 : One stitch compensating stitching operation (upper stop
/
upper stop)
is performed only when aforementioned changeover is made.
#4
Function of pedal curve selection (Function setting No. 87)
This function can perform the selection of the curve of number of rotation of the sewing machine against
the depressing amount of the pedal.
Change to this function when you feel that inching operation is hard or that pedal response is slow.
Number of rotation (rpm)
Pedal stroke (mm)
0
1
2
#2
Function to select the start-up speed of the sewing machine (Function setting No. 76)
This function is selected in the case where the speed of the sewing machine is desired to be more at the
time of start-up. (Time required to start is shortened by approximately 10%.)
0 : Normal curve
1 : More sharp curve
(Caution) If “1” is set, motor may move irregularly. In addition, noise may occur when the sewing
machine is running or noise may increase when the sewing machine is running.
#1
Retry function (Function setting No. 73)
When the retry function is used, if the sewing material is thick and not pierced with needle, this function
makes the needle pierce in the material with ease.
0 : Normal
1 : Retry function is provided.
#0
Function of reducing speed of reverse feed stitching at the start of sewing (Function setting No. 92)
Function to reduce speed at the time of completion of reverse feed stitching at the start of sewing : Normal
use depending on the pedal condition (Speed is accelerated to the highest without a break.)
This function is used when temporary stop is used properly. (Cuff and cuff attaching)
0 : Speed is not reduced.
1 : Speed is reduced.
Sew without stopping
without a break.
Temporary stop
7 6
0
7 3
1
8 4
1 0 0
#3
Presser foot lifting solenoid suction time setting (Function setting No. 84)
Suction time of presser foot lifting solenoid can be changed. When heating is great, it is effective to lessen
the value.
(Caution) When the value is excessively small, malfunction will be caused. So, be careful when
changing the value.
Setting range : 40 to 300ms <10/ms>
8 7
0
0 : Number of rotation of the sewing machine in terms of the
depressing amount of the pedal increases linearly.
1 : Reaction to intermediate speed in terms of the depressing amount
of the pedal is delayed.
2 : Reaction to intermediate speed in terms of the depressing amount
of the pedal is advanced.
9 3
0
9 0
1
#5
Initial motion UP stop position move function (Function setting No. 90)
Effective/ineffective of automatic return to UP stop position immediately after turning ON the power can be set.
0 : Ineffective
1 : Effective
9 2
0
