– 39 –
ENGLISH
#7
Continuous stitching + one shot stitching nonstop function (Function setting No. 94)
In IP-110 program functions, this is a function that does not stop the sewing machine at the last of a step
and proceeds to the next step when performing sewing by combining continuous stitching with one shot
stitching.
Select this function when you desire to execute the overlapped stitching of 19 stitches or more.
0 : Normal (Stop when a step has completed.)
1 : The sewing machine proceeds to next step without stopping after a
step has completed.
#8
Setting of max. number of rotation of the sewing machine head (Function setting No. 96)
This function can set the max. number of rotation of the sewing machine head you desire to use.
Upper limit of the set value varies in accordance with the sewing machine head to be connected.
50 to Max. [rpm] <50 / rpm>
#9
Sewing counter input function (Function setting No. 101)
This function can change over the count of the sewing counter displayed on the panel, when connecting
IP-100 panel, whether to the external sewing counter switch input or to the automatic updating by the inter-
nal thread trimming count.
0 : Every time thread trimming is performed, the counter automatically
counts up.
1 : Every time the sewing counter switch is inputted, the counter counts up.
9 6
4 0 0 0
9 4
0
1 0 1
0
1 2 0
– 2 8
1 2 1
0
1 2 2
0
$0
Main shaft reference angle compensation (Function setting No. 120)
Main shaft reference angle is compensated
Setting range
– 35 to 35˚ <1 / ˚>
$1
UP position starting angle compensation (Function setting No. 121)
Angle to detect UP position starting is compensated.
Setting range
– 15 to 15˚ <1 / ˚>
$2
DOWN position starting angle compensation (Function setting No. 122)
Angle to detect DOWN position starting is compensated.
Setting range
– 15 to 15˚ <1 / ˚>
