B 3
0999.GB
3 Technical data
A
Specification of technical data according to VDI 2198. Technical modifications and
supplements reserved.
3.1 Performance data
3.2 Dimensions
1)
with DZ hoist frame:+ 4 mm
Description EJB 14 EJB 16
Q Nominal load capacity 1400 1600 kg
C Load centre distance at standard fork length 600 600 mm
Driving speed with / without load 6.0 / 6.0 6.0 / 6.0 km/h
Lifting speed with / without load 15 / 23 14 / 23 cm/s
Lowering speed with / without load 44 / 42 40 / 40 cm/s
Max. hill-climbing ability with / without load 8 / 16 7 / 16 %
Description EJB 14 EJB 16
s lowered height of the load fork 40 40 mm
y Wheel base 1409 1409 mm
l
1
Truck length at fork length
1150 mm
2050 2050 mm
l
2
Length of front section 900 900 mm
B Truck width (Adjustable min/max) 1120 / 1570 1120 / 1570 mm
b
4
Dimension between wheel arms (adju-
stable)
900 - 1350 900 - 1350 mm
b
5
Overall distance of fork
(adjustable)
316 - 900 316 - 900 mm
m
2
Ground clearance 30 30 mm
Ast
Working corridor width
1)
1000 x 1200 diagonal
2162 2162 mm
Ast
Working corridor width
1)
800 x 1200 longitudinal
2362 2362 mm
Wa
Turning circle for shunt driving (raised
control shaft)
1629 1629 mm
B 3
0999.GB
3 Technical data
A
Specification of technical data according to VDI 2198. Technical modifications and
supplements reserved.
3.1 Performance data
3.2 Dimensions
1)
with DZ hoist frame:+ 4 mm
Description EJB 14 EJB 16
Q Nominal load capacity 1400 1600 kg
C Load centre distance at standard fork length 600 600 mm
Driving speed with / without load 6.0 / 6.0 6.0 / 6.0 km/h
Lifting speed with / without load 15 / 23 14 / 23 cm/s
Lowering speed with / without load 44 / 42 40 / 40 cm/s
Max. hill-climbing ability with / without load 8 / 16 7 / 16 %
Description EJB 14 EJB 16
s lowered height of the load fork 40 40 mm
y Wheel base 1409 1409 mm
l
1
Truck length at fork length
1150 mm
2050 2050 mm
l
2
Length of front section 900 900 mm
B Truck width (Adjustable min/max) 1120 / 1570 1120 / 1570 mm
b
4
Dimension between wheel arms (adju-
stable)
900 - 1350 900 - 1350 mm
b
5
Overall distance of fork
(adjustable)
316 - 900 316 - 900 mm
m
2
Ground clearance 30 30 mm
Ast
Working corridor width
1)
1000 x 1200 diagonal
2162 2162 mm
Ast
Working corridor width
1)
800 x 1200 longitudinal
2362 2362 mm
Wa
Turning circle for shunt driving (raised
control shaft)
1629 1629 mm
