0999.GB
E 2
2 Description of controls and indicating instruments
Pos. Controls or
indicating instrument
respectively
EJB
14/16
Function
1 Master switch
(Emergency Stop)
t
The circuit is interrupted, all electric
functions are switched off. The truck is
compulsory braked.
2 Key switch
t
Switches the control current on and
off. When the key is removed from the
key switch, the truck cannot be opera-
ted by unauthorised persons.
3 Combined instrument
o
Indicates the remaining capacity of the
battery and the hours of operation that
truck has already performed
(see chapter D).
4 Control shaft
t
Steering and braking the truck.
5 Button - Shunt driving
t
If the control shaft is in the upper bra-
king range, the braking function can be
by-passed by pressing
this button. The truck can only be mo-
ved with reduced speed (shunt dri-
ving).
6 Driving regulator
t
Controls the driving direction
driving speed.
7 Collision-guard
button
t
Truck drives away from the operator
and stops.
8 Button -
Lifting the lifting device
t
Lifting the lifting device.
The lifting speed can be continuously
adjusted with this key (adjustment ran-
ge 8 mm).
9 Button -
Lowering the lifting de-
vice
t
Lowering the lifting device.
The lowering speed can be conti-
nuously adjusted with this key (adjust-
ment range 8 mm).
10 Button - warning signal
(horn)
t
Trigger warning signal.
11 Terminal strip
t
Depositing of freight documents.
12 Document case
o
Used for depositing documents
t
= Standard equipment
o
= Optional equipment
0999.GB
E 2
2 Description of controls and indicating instruments
Pos. Controls or
indicating instrument
respectively
EJB
14/16
Function
1 Master switch
(Emergency Stop)
t
The circuit is interrupted, all electric
functions are switched off. The truck is
compulsory braked.
2 Key switch
t
Switches the control current on and
off. When the key is removed from the
key switch, the truck cannot be opera-
ted by unauthorised persons.
3 Combined instrument
o
Indicates the remaining capacity of the
battery and the hours of operation that
truck has already performed
(see chapter D).
4 Control shaft
t
Steering and braking the truck.
5 Button - Shunt driving
t
If the control shaft is in the upper bra-
king range, the braking function can be
by-passed by pressing
this button. The truck can only be mo-
ved with reduced speed (shunt dri-
ving).
6 Driving regulator
t
Controls the driving direction
driving speed.
7 Collision-guard
button
t
Truck drives away from the operator
and stops.
8 Button -
Lifting the lifting device
t
Lifting the lifting device.
The lifting speed can be continuously
adjusted with this key (adjustment ran-
ge 8 mm).
9 Button -
Lowering the lifting de-
vice
t
Lowering the lifting device.
The lowering speed can be conti-
nuously adjusted with this key (adjust-
ment range 8 mm).
10 Button - warning signal
(horn)
t
Trigger warning signal.
11 Terminal strip
t
Depositing of freight documents.
12 Document case
o
Used for depositing documents
t
= Standard equipment
o
= Optional equipment
