4.1 Truck identification label
A
In the event of queries relating to the truck or spare part orders, please state the serial
no. (28) of the truck.
4.2 Load capacity
f
The label (18) includes a table indicating
the loading capacity
(Q in kg) in relation to the load centre di-
stance (D in mm) and the lifting height (H
in mm).
The arrow-shaped markings on the inner mast (39) and outer mast
(40) show the driver when he has reached the lifting height limits that
is defined on the load capacity label (18).
Item Description Item Description
27 Model 33 Load centre distance in mm
28 Serial no. 34 Min./max. battery weight in kg
29 Order no. 35 Net weight without battery in kg
30 Nominal load capacity in kg 36 Year of manufacture
31 Battery: Voltage V
Ampere hours Ah
37 Type no.
32 Maker 38 Maker’s logotype
