Jungheinrich EKS 310 - Page 66

E 31
0206.GB
Adjust the steering angle
F
The battery must be disconnected when
adjusting the steering angle.
Using an Allen key set the steered wheel
to the required direction via the screw in
the steering motor (46).
Z
It is advisable to discharge the wheel if
setting an angle greater than 4 degrees.
46
