• Table 35 on page 113 for 10/100/1000BASE-T Ethernet Network Port Connector Pinout
Informaon.
• Table 36 on page 113 for SFP Network Port Connector Pinout Informaon.
• Table 37 on page 115 for SFP+ Network Port Connector Pinout Informaon.
Table 35: 10/100/1000BASE-T Ethernet Network Port Connector Pinout Informaon
Pin Signal Descripon
1 TRP1+ Transmit/receive data pair 1
Negave Vport (in PoE models)
2 TRP1- Transmit/receive data pair 1
Negave Vport (in PoE models)
3 TRP2+ Transmit/receive data pair 2
Posive Vport (in PoE models)
4 TRP3+ Transmit/receive data pair 3
5 TRP3- Transmit/receive data pair 3
6 TRP2- Transmit/receive data pair 2
Posive Vport (in PoE models)
7 TRP4+ Transmit/receive data pair 4
8 TRP4- Transmit/receive data pair 4
Table 36: SFP Network Port Connector Pinout Informaon
Pin Signal Descripon
1 VeeT Module transmier ground
113

Juniper EX4100 Specifications

General

Model	EX4100
Category	Switch
Layer	Layer 2/3
Power Consumption	Varies by model and configuration
PoE	Optional
Management	Web UI, CLI, SNMP
Operating Temperature	0°C to 45°C
Input Voltage	100-240V AC
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
DC Power Input	-48V DC
JUNOS OS	Yes
Security Features	ACLs
Layer 2 Features	VLAN, RSTP, MSTP, LACP
Layer 3 Features	Static routing, OSPF
QoS	8 queues per port
