Juniper EX4100 User Manual

1. Ensure that you have the correct fan module. The direcon of the airow in the fan module must
match the direcon of the airow in the installed power supply.
2. Aach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the
chassis.
3. Remove the fan module from its bag.
4. Hold the handle of the fan module with one hand, and support the weight of the module with the
other hand. Place the fan module in the fan module slot on the rear panel of the switch, and slide it in
unl it is fully seated.
5. Hand ghten the capve screws on the faceplate of the fan module. If you are unable to hand
ghten the capve screws, use the screwdriver.
Figure 99: Install a Fan Module in an EX4100 Switch
NOTE: If you have a Juniper J-Care service contract, register any addion, change, or upgrade of
hardware components at hps://www.juniper.net/customers/support/tools/updateinstallbase/.
Failure to do so can result in signicant delays if you need replacement parts. This note does not
apply if you replace exisng components with the same type of component.
SEE ALSO
Cooling System and Airow in an EX4100 and EX4100-F Switch | 53
181

Juniper EX4100 Specifications

General

Model	EX4100
Category	Switch
Layer	Layer 2/3
Power Consumption	Varies by model and configuration
PoE	Optional
Management	Web UI, CLI, SNMP
Operating Temperature	0°C to 45°C
Input Voltage	100-240V AC
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
DC Power Input	-48V DC
JUNOS OS	Yes
Security Features	ACLs
Layer 2 Features	VLAN, RSTP, MSTP, LACP
Layer 3 Features	Static routing, OSPF
QoS	8 queues per port
