Table 33: Inventory of Components Provided with an EX3200 or EX4200 Switch (continued)
QuantityComponent
1RJ-45 cable and RJ-45 to DB-9 serial port adapter
1Virtual Chassis cable (for an EX4200 switch)
2Virtual Chassis cable connector retainers (for an EX4200 switch)
24Dust covers for ports (for an EX4200-24F switch)
Related Topics Mounting an EX3200 or EX4200 Switch on page 120•
• Installing and Connecting an EX3200 or EX4200 Switch on page 117
• Connecting and Configuring an EX Series Switch (CLI Procedure) on page 165
• Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 167
Mounting an EX3200 or EX4200 Switch
You can mount an EX3200 or EX4200 switch:
•
On two posts in a 19-in. rack or cabinet by using the mounting brackets provided with
the switch.
•
On four posts in a 19-in. rack or cabinet by using the separately orderable four-post
rack-mount kit.
•
In a position recessed 2 in. from the front of a 19-in. rack or cabinet by using the
2-in.-recess front brackets in the separately orderable four-post rack-mount kit. You
can mount the switch in this recessed position on two-post or four-post racks and
cabinets.
•
On a desk or other level surface by using rubber feet. The switch is shipped with four
rubber feet to be used to stabilize the chassis on a desk or other level surface.
•
On a wall by using the separately orderable wall-mount kit.
The holes in the mounting brackets are placed at 1 U (1.75 in. or 4.45 cm.) apart so that
the switch can be mounted in any rack or cabinet that provides holes spaced at that
distance.
Related Topics Mounting an EX3200 or EX4200 Switch on Two Posts in a Rack or Cabinet on page 122•
• Mounting an EX3200 or EX4200 Switch on Four Posts in a Rack or Cabinet on page 124
• Mounting an EX3200 or EX4200 Switch in a Recessed Position in a Rack or Cabinet
on page 128
• Mounting an EX3200 or EX4200 Switch on a Desk or Other Level Surface on page 121
• Mounting an EX3200 or EX4200 Switch on a Wall on page 128
Copyright © 2010, Juniper Networks, Inc.120
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches
