Table 23: Uplink Modules Connector Pinout Information for EX3200 and EX4200

Switches (continued)

Pin NamePin Number

GNDA10

GNDA11

GNDA12

GNDA13

GNDA14

Uplink_I2C_SCKA15

GNDA16

Uplink_PDA17

GNDA18

POWER (12V)A19

GNDA20

GNDB1

XAUI0_RX0NB2

GNDB3

XAUI0_RX2NB4

Uplink_P25_LED2B5

XAUI1_RX0NB6

Uplink_P27_LED2B7

XAUI1_RX2NB8

GNDB9

SRX28NB10

Uplink_XAUI_XMDIOB11

SRX26NB12
