EX3200 Switch Models
TheEX3200 switchis availablewith 24 or 48 ports with partial or full Powerover Ethernet
(PoE) capability. Table 1 on page 6 lists the EX3200 switch models.
Table 1: EX3200 Switch Models
Power Supply
(Minimum)
Number of
PoE-enabled PortsAccess PortsTypical DeploymentModel
320 WFirst 8 ports24 Gigabit EthernetAccess or Distribution
switch
EX3200-24T
600 WAll 24 ports24 Gigabit EthernetAccess switchEX3200-24P
320 WFirst 8 ports48 Gigabit EthernetAccess or Distribution
switch
EX3200-48T
930 WAll 48 ports48 Gigabit EthernetAccess switchEX3200-48P
Related Topics EX4200 Switch Models on page 6•
• Front Panel of an EX3200 Switch on page 7
• Rear Panel of an EX3200 Switch on page 8
• EX3200 and EX4200 Switches Hardware Overview on page 3
EX4200 Switch Models
The EX4200 switch is available with 24 or 48 ports and with partial or full Power over
Ethernet (PoE) capability. Table 2 on page 6 lists the EX4200 switch models.
Table 2: EX4200 Switch Models
Power Supply
(Minimum)Number of PoE-enabled PortsPortsModel
320 WFirst 8 ports24 Gigabit EthernetEX4200-24T
600 WAll 24 ports24 Gigabit EthernetEX4200-24P
320 WFirst 8 ports48 Gigabit EthernetEX4200-48T
930 WAll 48 ports48 Gigabit EthernetEX4200-48P
320 WNot applicable24 small form-factor pluggable
(SFP) transceivers
EX4200-24F
Related Topics EX3200 Switch Models on page 6•
• Front Panel of an EX4200 Switch on page 9
Copyright © 2010, Juniper Networks, Inc.6
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches

Juniper EX4200 Series Specifications

General

Switching Capacity	128 Gbps
Ports	24 or 48 10/100/1000BASE-T ports
Virtual Chassis	Up to 10 switches
Layer 3 Routing	Yes
Maximum VLANs	4096
DRAM	1 GB
Flash Memory	1 GB
Humidity	5% to 90% non-condensing
Power Supply	AC or DC options
MAC Address Table Size	32, 000 entries
Operating Temperature	0°C to 45°C
Layer 2 Features	VLAN, STP, RSTP, MSTP, LACP
Management	CLI, Web UI, SNMP
Storage Temperature	-40°C to 70°C
Input Voltage	AC: 100-240V; DC: -48V
