Table 18: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP

Transceivers in EX3200 and EX4200 Switches (continued)

SpecificationsEthernet Standard

EX-SFP-1GE-LHModel Number1000Base-LH (or

1000Base-ZX)

1000 MbpsRate

LCConnector Type

DualFiber Count

1550 nmTransmitter Wavelength

–2 dBmMinimum Launch Power

5 dBmMaximum Launch Power

–25 dBmMinimum Receiver Sensitivity

–3 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

70 km (43.5 miles)Distance

AvailableDOM Support

Junos OS for EX Series switches, Release 9.0 or laterSoftware required
