Table 19: Optical Interface Support for Fast Ethernet SFP Transceivers in EX3200 and EX4200

Switches (continued)

SpecificationsEthernet Standard

EX-SFP-1FE-LX40KModel Number100Base-LX40K

100 MbpsRate

LCConnector Type

DualFiber Count

1310 nmTransmitter Wavelength

–5 dBmMinimum Launch Power

0 dBmMaximum Launch Power

–32 dBmMinimum Receiver Sensitivity

–8 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

40 km (24.8 miles)Distance

Not availableDOM Support

Junos OS for EX Series switches, Release 10.0 or laterSoftware required
