Juniper SRX110 Hardware Guide

APPENDIX C
SRX110 Services Gateway Interface Cable
Specifications and Connector Pinouts
The network interfaces supported on the services gateway accept different types of
network cables.
This appendix includes the following topics:
•
Interface Cable and Wire Specifications for the SRX110 Services Gateway on page 135
•
RJ-45 Connector Pinouts for the SRX110 Services Gateway Ethernet Port on page 136
•
RJ-45 Connector Pinouts for the SRX110 Services Gateway Console Port on page 137
•
RJ-11 Connector Pinouts for the SRX110 Services Gateway on page 138
Interface Cable and Wire Specifications for the SRX110 Services Gateway
Table 45 on page 135 lists the specifications for the cables that connect to ports.
Table 45: Cable and Wire Specifications for Ports
Device Receptacle
Maximum
LengthCable/Wire RequiredCable SpecificationPort
RJ-456 ft
(1.83 m)
One 6 ft (1.83 m) length
with DB-9/RJ-45
connectors
RS-232 (EIA-232)
serial cable
Console
port
RJ-45328 ft
(100 m)
One 15 ft (4.57 m)
length with RJ-45/RJ-45
connectors
CAT-5e (Category 5)
cable or equivalent
suitable for
100BASE-T
operation
Ethernet
port
•
For
VDSL/ADSL-POTS:
RJ-11
•
For
VDSL/ADSL-ISDN:
RJ-45
18K ft
(5.486K
m)
•
For
VDSL/ADSL-POTS:
One 10 ft (3.048 m)
with RJ-11 connector
•
For
VDSL/ADSL-ISDN:
One 10 ft (3.048 m)
with RJ-45 connector
•
For
VDSL/ADSL-POTS:
RJ-11 cable
•
For
VDSL/ADSL-ISDN:
RJ-11/RJ-45 cable
VDSL2
port
135Copyright © 2013, Juniper Networks, Inc.

Juniper SRX110 Specifications

General

Memory	1 GB
Flash	1 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Interfaces	8 x 10/100/1000 Ethernet
Power Supply	AC 100-240V, 50-60 Hz
Humidity	10% to 90% non-condensing
