An OK response verifies that the modem can communicate successfully with the COM

port on the PC or laptop.

6. Configure the modem to answer a call on the first ring by entering ATS0=1.

7. Configure the modem to accept modem control DTR signals by entering AT&D1.

8. Disable flow control by entering AT&K0.

9. Save modem settings by entering AT&W.

Documentation

Connecting the Modem to the Console Port on the SRX110 Services Gateway on page 80•

• Connecting to the CLI at the User End for the SRX110 Services Gateway on page 81

• SRX110 Services Gateway Software Configuration Overview on page 83

Connecting the Modem to the Console Port on the SRX110 Services Gateway

To connect the dial-up modem to the console port on the services gateway:

1. Turn off power to the services gateway.

2. Turn off power to the modem.

3. Plug one end of the Ethernet cable supplied with your services gateway into the

console port on the services gateway.

4. Plug the other end of the CAT-5e cable (Ethernet cable) into the RJ-45 to DB-9 serial

port adapter supplied with your services gateway.

5. Connect the serial port adapter to a separately purchased DB-9 female to DB-25

male adapter or other adapter appropriate for your modem.

6. Plug the modem adapter into the DB-25 connector on the modem.

7. Connect the modem to your telephone network.

8. Turn on the power to the modem.

9. Power on the services gateway by pressing the Power button on the front panel. Verify

that the Power LED on the front panel turns green.

NOTE: Most modems have an RS-232 DB-25 connector. You must

separately purchase an adapter to connect your modem to the RJ-45 to

DB-9 adapter and the Ethernet cable supplied with the services gateway.

Documentation

Connecting the Modem at the SRX110 Services Gateway End on page 79•

• Connecting to the CLI at the User End for the SRX110 Services Gateway on page 81

• SRX110 Services Gateway Software Configuration Overview on page 83
