Figure 10: 3G USB Modem with USB Protection Cover
g033622
Table 14 on page 25 lists the components of the 3G USB modem with USB protection
cover.
Table 14: 3G USB Modem with USB Protection Cover Components
ComponentNumber
USB mount top cover1
USB modem2
USB mount (magnetic/non-magnetic)3
USB mount base4
Lock5
To connect the 3G USB modem on the USB modem extension cable-mount:
1. Place the USB mount on the USB mount base.
2. Insert a 3G USB modem in the USB mount slot.
3. Close the USB mount top cover on the USB mount.
4. Lock the USB modem protection cover.
