To install the device on a wall:
1. Place the device on a flat, level surface, with the Juniper Networks logo facing up. The
logo is embossed on the top cover. Ensure that the rubber feet are attached to the
bottom of the chassis.
2. Position a mounting bracket on each side of the chassis as shown in
Figure 21 on page 64.
Figure 21: SRX110 Services Gateway Wall Installation — Attaching the
Mounting Brackets
g033615
Table 30 on page 64 lists the parts to use to install the SRX110 Services Gateway on
a wall. The numbers in Figure 21 on page 64 correspond to the numbers in
Table 30 on page 64.
Table 30: SRX110 Services Gateway Wall Installation Parts
PartNumber
Mounting brackets1
Screws (mounting bracket)2
3. Use a Phillips (+) screwdriver, number 1, to install the screws that secure the mounting
brackets to the chassis.
4. If you are using wall anchors to support the chassis, install two pairs of anchors on
the wall.
5. Have one person grasp the sides of the device, lift it, and position it on the wall.
6. Have a second person install two pairs of mounting screws through the bracket holes
on either side of the device to secure it to the wall.
7. Verify that the mounting screws on one side are aligned with the mounting screws on
the opposite side and that the device is level (Figure 22 on page 65).
Copyright © 2013, Juniper Networks, Inc.64
SRX110 Services Gateway Hardware Guide

Juniper SRX110 Specifications

General

Memory	1 GB
Flash	1 GB
Operating Temperature	32°F to 104°F (0°C to 40°C)
Interfaces	8 x 10/100/1000 Ethernet
Power Supply	AC 100-240V, 50-60 Hz
Humidity	10% to 90% non-condensing
