Juniper SRX345 Hardware Guide

CHAPTER 6
Planning and Preparing the Site
•
SRX345 Services Gateway Physical Specifications on page 19
•
SRX345 Services Gateway Environmental Specifications on page 19
•
Site Preparation Checklist for the SRX345 Services Gateway on page 20
•
General Site Installation Guidelines for the SRX345 Services Gateway on page 22
SRX345 Services Gateway Physical Specifications
Table 7 on page 19 lists the physical specifications for the services gateway.
Table 7: Physical Specifications for the SRX345 Services Gateway
With Dual AC Power SuppliesWith Single AC Power SupplyPhysical Specification of Chassis
18.70 in. (47.50 cm)14.57 in. (37.01 cm)Depth
17.36 in. (44.09 cm)17.36 in. (44.09 cm)Width
1.72 in. (4.37 cm)1.72 in. (4.37 cm)Height
14.34 lb (6.50 kg)10.80 lb (4.90 kg)Weight
Related
Documentation
Understanding the SRX345 Services Gateway Front Panel on page 5•
• Understanding the SRX345 Services Gateway Back Panel on page 8
• SRX345 Services Gateway Environmental Specifications on page 19
SRX345 Services Gateway Environmental Specifications
Table 8 on page 20 provides the required environmental conditions for normal SRX345
Services Gateway operations.
19Copyright © 2017, Juniper Networks, Inc.

Juniper SRX345 Specifications

General

USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	8
Flash memory	8000 MB
Internal memory	4000 MB
Certification	FCC A, RoHS 2
Rack capacity	1U
Heat dissipation	420 BTU/h
Power consumption (typical)	122 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, MPLS, OSPF, RIP-1, RIP-2
Supported network protocols	IPv4, IPv6
Firewall security	Yes
Security algorithms	IPSEC, SSL/TLS
Networking standards	IEEE 802.1p
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Weight	4900 g
Dimensions (WxDxH)	440.9 x 370.1 x 43.6 mm
