CHAPTER 14
Installing the SRX345 Services Gateway
in a Rack
•
Installing the SRX345 Services Gateway into a Rack on page 51
Installing the SRX345 Services Gateway into a Rack
You can front-mount the SRX345 Services Gateway in a rack. Many types of racks are
acceptable, including four-post (telco) racks, enclosed cabinets, and open-frame racks.
NOTE: If you are installing multiple devices in one rack, install the lowest one
first and proceed upward in the rack.
To install the services gateway in a rack:
1. Position a mounting bracket on each side of the chassis.
2. Use a number-2 Phillips (+) screwdriver to install the screws that secure the mounting
brackets to the chassis. Use either the front mount position, as shown in
Figure 9 on page 51, or the center mount position, as shown in Figure 10 on page 52.
Figure 9: Installing the Rack Mount Brackets (Front Mount Position)
51Copyright © 2017, Juniper Networks, Inc.
