Juniper SRX5400 - Page 61

Figure 28: SRX-MIC-2X40G QSFP
Descripon
• MIC with two QSFP+ Ethernet ports
• Fits into MPC
• Supports up to 80 Gbps of full-duplex trac
• Maximum congurable MTU: 9192 bytes
• Maximum throughput: 80 Gbps
Soware release Junos OS Release 12.1X46-D10
Cables and connectors Sockets for two QSFP+ 40-Gigabit Ethernet ber-opc transceivers.
Supported QSFP+ transceiver:
40GBASE-SR4 (model number SRX-QSFP-40G-SR4)
40GBASE-LR4 (model number SRX-QSFP-40G-LR4)
Supported slots Either slot in SRX5K-MPC
Weight Approximately 1.6 lb (0.7 kg)
57
