Juniper SRX5400 - SRX5 K-IOC4-MRAT Specifications

Serial Number Locaon The serial number label is located as shown in Figure
35 on page 70.
Figure 35: SRX5K-IOC4-10G Serial Number
Label
SRX5K-IOC4-MRAT Specicaons
SRX5K-IOC4-MRAT is a xed-conguraon interface card with a Packet Forwarding Engine that
provides up to 480-Gbps (240-Gbps per PIC slot) line rate. This interface card provides scalability in
bandwidth and services to the SRX5400, SRX5600, and SRX5800 Firewalls. See Figure 36 on page 70.
NOTE: SRX5K-IOC4-MRAT cards do not support plug-in Modular Interface Cards (MICs).
Figure 36: SRX5K-IOC4-MRAT
If a slot in the SRX5400, SRX5600, or SRX5800 Firewall card cage is not occupied by a card, you must
install a blank panel to shield the empty slot and to allow cooling air to circulate properly through the
rewall.
70
