NOTE: SRX5K-IOC4-10G cards do not support plug-in Modular Interface Cards (MICs).
Figure 34: SRX5K-IOC4-10G
If a slot in the SRX5400, SRX5600, or SRX5800 Firewall card cage is not occupied by a card, you must
install a blank panel to shield the empty slot and to allow cooling air to circulate properly through the
rewall.
Descripon
• Fixed-conguraon IOC with forty 10-Gbps port
speeds
• Maximum throughput: 400-Gbps
• Maximum congurable MTU: 9192 bytes
Soware release Junos OS Release 19.3R1 and later
Supported slots
• SRX5400—Any slot, except the boom slots 0 and
1/0, which are reserved for SCB/RE.
NOTE: Slot 1/0 is a dual purpose slot. You can
install SRX5K-IOC4-10G in slot 1/0 if an SCB is not
already installed in it.
• SRX5600—Any slot, except the boom slots 0 and
1, which are reserved for SCB/RE.
• SRX5800—Any slot, except the middle slots 0, 1,
and 2/6, which are reserved for SCB/RE, and slots
0 (most le) and 11 (most right).
NOTE: Slot 2/6 is a dual purpose slot. You can
install SRX5K-IOC4-10G in slot 2/6 if an SCB is not
already installed in it.
