The serial number label is located as shown in
Figure 35 on page 63.
Figure 35: SRX5K-IOC4-10G Serial Number Label
g100575
Serial number
ID label
Serial Number Location
SRX5K-IOC4-MRAT Specifications
SRX5K-IOC4-MRAT is a fixed-configuration interface card with a Packet Forwarding Engine that provides
up to 480-Gbps (240-Gbps per PIC slot) line rate. This interface card provides scalability in bandwidth and
services to the SRX5400, SRX5600, and SRX5800 Services Gateways. See Figure 36 on page 63.
NOTE: SRX5K-IOC4-MRAT cards do not support plug-in Modular Interface Cards (MICs).
Figure 36: SRX5K-IOC4-MRAT
g100570
SRX5K-IOC4-MRAT
63
