Juniper SRX5400 - MIC with 1 X100 Ge CFP Interface (SRX-MIC-1 X100 G-CFP)

The serial number label is yellow and located as shown in Figure 25 on page 51.
Figure 25: SRX-MIC-10XG-SFPP Serial Number Label
Serial number
location
MIC with 1x100GE CFP Interface (SRX-MIC-1X100G-CFP)
You use MICs and MPCs to add different combinations of Ethernet interfaces to your services gateway
to suit the specific needs of your network. The SRX-MIC-1X100G-CFP (see Figure 26 on page 51) can be
installed in an MPC to add one 100-Gigabit Ethernet CFP port.
Figure 26: SRX-MIC-1X100G-CFP
g030310
•
MIC with one CFP 100-Gigabit Ethernet port
•
Fits into MPC
•
Supports up to 100 Gbps of full-duplex traffic
•
Maximum configurable MTU: 9192 bytes
•
Maximum throughput: 100 Gbps
Description
Junos OS Release 12.1X46-D10Software release
51
